- Place of Origin: Shandong
- Brand Name: hongfa machinery
- Model Number: QMJ-12A
Brief introduction
1)QMJ-12A has larger productivity than the other small block machines.This kind of brick machine is manufactured on the base of technical modifications to the original block shaping machines,that is changing the former one-time-vibration into twice-vibrations of molding core.So the block density becomes higher,shaping speed quicker and block strength more even.This model of machine can be suitable to the customers who have any kinds of existing cement working sites.
2)Advanced techniques made the host machine designed reasonably,and achieved box vibration,hydraulic stripping,omnidirectional automatically movement.QMJ-12A works faster because of automatically feeding system.High quality of steel and precision welding made the machine a longer service life and hydraulic system made less fault during work.
3)QMJ-12A has several function features,such as low price,reliable performance,easy operated,stable,lower power consumption(just one sixth power consumption of the machine which has the same output).Mass raw material can be used during production,for concrete,cement,small stone,powder,san,coal gangue,slag,construction waste and so on.
Raw materials
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.
Pre-sale service support:
According to each customer's demand and budget, we offer you the professional solution, process flow design and production equipment. More importantly, we welcome every customer to visit our factory and working machine in the site before placing the order. We will arrange cars, hotels and translators for the visiting customers.
During-sale service support:
Assist clients to finish the factory planning. Before delivery equipment to customer s, complete debugging and checking. Provide a full instruction manual for the whole system. Provide technical guidance for the installation and use of the unit, including installation advice and electrical connection. Provide unit debugging and training for the operation of the machine on the working site and coordiante the customers with check and acceptance of the unit.
After-sale service support:
Send technicians to installation site for the guidance, equipment adjustment and training. Provide high-quality spare parts thoughout the year, and the maintenance technicians are always ready to provide technical help.
- Place of Origin: Shandong
- Brand Name: hongfa machinery
- Model Number: QMJ-12A
Breif introduction
Overall dimension | 3300*2100*2400mm |
Hydraulic method | Mould vibration |
Demold method | Hydraulic |
Turning method | Hydraulic |
Hydraulic system pressure | 16-20Mpa |
Excitation frequency | 3200Hz |
Total power | 17.5KW |
Total mass | 4500KG |
Molding cycle | 20S |
Molding size (L*W) | 1200*860mm |
Molding | 12 Pcs/mould(400*200*200/390*190*190 mm) |
Capacity | 1200-1500Pcs/hour |
Types of bricks can be made | 390*240*190/390*150*190/390*115*190/Customize |
Moving method | Automatically move and hydraulic steering |
Excitation way | Three-dimensional box excitation |
Productivity
Item | Size(MM) | Quantity | Cycle molding | Per day 10 hours |
Hollow block |
400×200×200 |
12pcs/mould |
20~25s |
14000pcs |
400×140×200 |
14pcs/mould |
20~25s |
18000 pcs | |
400×120×200 |
18pcs/mould |
20~25s |
24000pcs |
