- Place of Origin: Shandong
- Brand Name: hongfa machinery
- Model Number: QT10-15
Brief Introduction
Particular stronge and discerption material system insure the feeding accuracy and avoiding the effect of exterior material. So the products have high density. Adopting synchronization vibration insures the products making average. The frequency can change according to different material to have to a optimal vibration way. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny, controlling, diagnosis.
- Place of Origin: Shandong
- Brand Name: hongfa machinery
- Model Number: QT10-15
Theoretical productivity
Item | Specification size | Quantity per mold | Cycle molding | Per hour | Per year |
Hollow brick | 390*190*190mm | 10pcs | 20-25s | 1400-1800pcs | 4320000-5400000pcs |
Porous brick | 240*115*90mm | 24pcs | 15-20s | 4320-5760pcs | 12960000-17280000pcs |
Standard brick | 240*115*53mm | 52pcs | 15-17s | 11011-12480pcs | 33030000-37440000pcs |
Technical parameter
Overall diamension | 9350*3000*2900mm |
Rated pressure | 21MPa |
Main vibration | Platform vibration |
Vibration frequency | 2800-4500(r/min) |
Pallet size | 1100*900mm |
Molding cycle | 15-25s |
Exciting force | 110KN |
Overall power | 67KW |
