- Place of Origin: Shandong
- Brand Name: hongfa machinery
- Model Number: QT6-15
- Weight: 6200.000 kg
Brief introduction
1)It is a compact oil hydraulic machine according to the standard of international.Many parts from abroad ensure the quality of machine and take fro the power.
2)The vibration system contains platform vibration and mould vibration so the products is very close grained and produced quickly.
3)The novel feeding system gives material exactly and average and assures the products having a high density.
Raw materials
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.
- Place of Origin: Shandong
- Brand Name: hongfa machinery
- Model Number: QT6-15
- Weight: 6200.000 kg
Main technical specification
| Overall Dimension | 7100*1500*3000mm |
| Rated Pressure | 16MPa |
| Main vibration form | Platform vibration |
| Cycle Time | 15-25 seconds |
| Vibrating Frequency | 4500-5100 rolls/minute |
| Motors Power | 31.25kw |
| Pallet Size | 850*680(mm) |
Productivity
Brick Style | Size(mm) | Cycle molding | QTY/Mould | Per hour |
Hollow brick
| 400*200*200 | 16-20s | 6 pcs | 960~1080pcs |
240*115*90 | 15-20s | 18 pcs | 3800~4050pcs | |
Color brick |
225*112.5*60
| 15-17s | 36 pcs | 4900~5800pcs |
